Computar cctv lenses, C mount all new and boxed |
2/3" |
C |
12.5 - 75mm | f1.2-16C | 38.3-6.7° |
1.2m |
Manual Focus, Zoom & Iris |
Computar H3616F1 3.6mm F1.6
1/2" |
C |
3.6mm | f1.6-16C | 92.6° |
0.2m |
Manual Iris & Focus |
Computar HAS0612APC
1/2" |
C |
6mm | f1.2-360 | 56.6° |
0.2m |
Manual Focus, w/Amp, No Plug |
1/2" C-MOUNT Computar lenses
| Part no | F length | Aperture | angle of view | mod | effective aperture front |
effective aperture rear | filter size | Weight |
| H6Z8512AMS | 8.5-51 | F1.2- 560C |
42.2- 7.1 |
1.0 | 40.4 | 14.4 | 46.0 | 620 |
| H10Z0812AMS | 8-80 | F1.2- 560 |
44.0- 4.7 |
1.5 | 54.0 | 14.0 | 62.0 | 660 |
| 4.0 mm f 1.4 auto Iris Direct Drive lens (Part number: 15-L040D) 4.0 mm direct drive auto iris manual focus lens for use with body cameras CS mount |
 |
A 4mm direct drive auto Iris, manual focus lens that can be used with cop body cameras
Features include:-
For use with 1/3" or 1/4" cameras,
High Quality,
Pre fitted plug,
F1.4,
4.0mm
| 8.0 mm f 1.4 auto Iris Direct Drive lens (Part number: 15-L080D) 8.0 mm direct drive auto iris manual focus lens for use with body cameras CS mount |
|
A 8mm direct drive auto Iris, manual focus lens that can be used with cop body cameras
Features include:-
For use with 1/3" or 1/4" cameras,
High Quality,
Pre fitted plug,
F1.4,
4.0mm
| 12.0 mm f 1.4 auto Iris Direct Drive lens (Part number: 15-L120D) 12.0 mm direct drive auto iris manual focus lens for use with body cameras CS mount |
|
A 12mm direct drive auto Iris, manual focus lens that can be used with cop body cameras
Features include:-
For use with 1/3" or 1/4" cameras,
High Quality,
Pre fitted plug,
F1.4,
12.0mm
| Mini 2.5 mm f 2.0 fixed iris lens (Part number: 15-L025S) 2.5mm Mini Lens used for fitting to covert, dome, finger and mini cameras as an option |
 |
A 2.5mm lens that can be used to upgrade some of the cop cameras EG: finger and dome cameras
Features include:-
For use with 1/3" or 1/4" cameras,
High Quality,
F 2.0
2.5mm
| Mini 6.0 mm f 2.0 fixed iris lens (Part number: 15-L060S) 6.0mm Mini Lens used for fitting to covert, dome, finger and mini cameras as an option |
 |
A 6.0mm lens that can be used to upgrade some of the cop cameras EG: finger and dome cameras
Features include:-
For use with 1/3" or 1/4" cameras,
High Quality,
F 2.0
6.0mm
SPECIFICATIONS
Size 6.0mm
f Stop f 2.0
Angle 53 Degrees
| Mini 8.0 mm f 2.5 fixed iris lens (Part number: 15-L080S) 8.0mm Mini Lens used for fitting to covert, dome, finger and mini cameras as an option |
 |
A 8.0mm lens that can be used to upgrade some of the cop CCTV cameras EG: finger and dome cameras
Features include:-
For use with 1/3" or 1/4" cameras,
High Quality,
F 2.0
8.0mm
SPECIFICATIONS
Size 8.0mm
f Stop f 2.0
Angle 40 Degrees
| Mini 12.0 mm f 2.5 fixed iris lens (Part number: 15-L120S) 12mm Mini Lens used for fitting to covert, dome, finger and mini cameras as an option |
 |
A 12.0mm lens that can be used to upgrade some of the cop cameras EG: finger and dome cameras
Features include:-
For use with 1/3" or 1/4" cameras,
High Quality,
F 2.0
12.0mm
SPECIFICATIONS
Size 12.0mm
f Stop f 2.0
Angle 25 Degrees
| 3.5-8.0 mm f 1.4 manual iris varifocal lens (Part number: 15-L3508M) 3.5-8.0 mm varifocal manual iris manual focus lens for use with body cameras CS mount |
 |
Features include:-
For use with 1/3" or 1/4" cameras,
High Quality,
3.5mm to 8.0mm,
F1.4
A 3.5 mm to 8.0 mm Varifocal manual Iris, manual focus lenses that can be used with cop body cameras.
| 3.5-8.0 mm f 1.4 varifocal auto Iris Direct Drive lens (Part number: 15-L3508ZD) 3.5-8.0 mm varifocal direct drive auto iris manual focus lens for use with body cameras CS mount |
 |
A 3.5 mm to 8.0 mm Varifocal direct drive auto Iris, manual focus lenses that can be used with cop body cameras.
Features include:-
For use with 1/3" or 1/4" cameras,
High Quality,
Pre fitted plug,
3.5mm to 8.0mm,
F1.4
| 5.0-50.0mm f 1.2 varifocal auto Iris Direct Drive lens (Part number: 15-L0660ZD) 5.0-50.0mm varifocal direct drive auto iris manual focus lens for use with body cameras CS mount |
 |
A 6.0 mm to 60.0 mm Varifocal direct drive auto Iris, manual focus lenses that can be used with cop body cameras.
Features include:-
For use with 1/3" or 1/4" cameras,
High Quality,
Pre fitted plug,
60mm to 60.0mm,
F1.2
SPECIFICATIONS
Size 6.0 to 60mm
f Stop f1.2
Angle 60 to 5 Degrees
CCTV LENSES
A Range of standard CCTV lenses designed to fit 1/3" format cameras.
4.0 mm 1/3" format with 80 deg view angle
6.0 mm 1/3" format with 53 deg view angle
8.0 mm 1/3" format with 40 deg view angle
12.0 mm 1/3" format with 28 deg view angle
