new range of power up and power house 12v dc inverters
| 150/300/500 watt DC
to AC Power inverter 12vDC - 240vAC |
| Introduction
A choice of three inverters 150w 300w and 500
w
This inverter supplies continuous 240v ac power via
a standard 13A socket and can be used to run almost any household or
electronic device or appliance up to 300w from a 12v battery (car, caravan
or boat battery) Safety features include automatic shutdown and a
low battery voltage alarm to prevent damage to your battery.
|
Specification
- Output connection: Standard 13A socket
- Output voltage: 240v AV (rms)
- Input voltage range: 11-15vdc
- low voltage alarm: approx 10.5v DC
- Low voltage shut down: approx 10v DC
- Input cables: both fitted with large 'crocodile'
clips
- Additional protective features: Overload,
overheat and over voltage protection
- Supplied with comprehensive user guide and
trouble shooting guide.
- Guarantee: 3 years
|
Why would you buy from us?
Well we have been in mail order since 1945
we have 10's of thousands of satisfied customers
You can ring us up 01273 491490
You can come and visit us at Unit D Henfield Business Park
Henfield Sussex
We have been selling inverters since some time last
century
| More inverter technical information
The DC to DC converter stage uses modern high
frequency power conversion techniques that have replaced bulky
transformers found in less technologically advanced models. The output is
known as 'modified sine wave' This type of waveform is suitable for most
types of AC load. |
|
Uses for the inverter include, but are not limited
to - games consoles, lap tops, xbox, digital camera chargers, video
players, video camera chargers, lamps and lights, DAB and conventional
mains radios, televisions, LCD televisions, CD players etc. |
POWER-UP INVERTERS The best name in power inverters brings you Instant Portable Power
(230v mains power from a 12v battery). The 150-200watt units can be used via a
Vehicle Cigar Lighter. If the equipment or appliance requires more than 150-watts you
should connect directly to the vehicle battery. Although rated at 150-watt continuous
the POWER-UI is able to deliver up to a 450-watts Power Surge for short periods, to
start applications such as TV's. When the engine is switched off most Car Batteries
can provide power for man hours. The actual length of time is dependent on the age
and condition of the Battery and the power demanded to run the equipment being
operated. The POWER-UP is available in a
range of sizes froml45 Watt up to 2.5Kw.
POWER-HOUSE INVERTERS
POWER-HOUSE units are designed for use in the Home or Office. In addition to the
POWER-UP features these Units are fully automatic with a built in Battery Charger.
When mains power is disconnected it takes only 4ms to switch over to the battery
powered 230v POWER-HOUSE . The Battery is recharged automatically when mains
power is restored. You will be able to run TV's, VCR's, Camcorders, Compact
Drills, Portable Power Tools, Soldering Irons, Shaver, Lighting, Desktop Computers,
Printers, Laptops, Nebulisers, Video Games, Cash Registers, Satellite receivers,
Stereos, Musical Instruments, Fans, and much more.
POWER UP MODIFIED SINE WAVE INVERTERS 12V INPUT 230V 50HZ OUTPUT
Type 12015 inverter 150 watt continuous 450 watt surge, 162x104x58mm .7kg
150
watt inverter
Type 12200 inverter 200 watt continuous 500 watt surge, 162x104x58mm .7kg
200
watt inverter
Type 12300 inverter 300 watt continuous 1kw surge, 250x104x58mm .9kg
300
watt inverter
Type 12600 inverter 600 watt continuous 1.5kw surge, 290x205x73mm 2.1kg
600
watt inverter
Type 12800 inverter 800 watt continuous 2.0kw surge 330x240x77mm 2.7kg
800 watt inverter
800
watt inverter
Type 12100 inverter 1.0 kw continuous 2.0kw surge 393x242x80mm 3.15kg
1.0
kw inverter
Type 12150 inverter 1.5kw continuous 3kw surge 430x240x77mm 3.8kg
1.5kw
inverter
Type 12250 inverter 2.5kw continuous 5.0kw surge 496x203x166mm 9kg
2.5kw
inverter
Power House inverters
POWER-HOUSE units are designed for use in the Home or Office. In addition to the
POWER-UP features these Units are fully automatic with a built in Battery Charger.
When mains power is disconnected it takes only 4ms to switch over to the battery
powered 230v POWER-HOUSE . The Battery is recharged automatically when mains
power is restored. You will be able to run TV's, VCR's, Camcorders, Compact
Drills, Portable Power Tools, Soldering Irons, Shaver, Lighting, Desktop Computers,
Printers, Laptops, Nebulisers, Video Games, Cash Registers, Satellite receivers,
Stereos, Musical Instruments, Fans, and much more.
Type 12C030 inverter with built in charger 300 watt continuous 1kw surge
300x104x58mm 1.9kg
300w
inverter with charger
Type 12C060 inverter with built in charger 600 watt continuous 1.5kw surge
330x205x73mm 2.8kg
600w
inverter with charger
Type 12C100 inverter with built in charger 1kw continuous 2kw surge
475x242x80mm 4.65kg
1kw
inverter with charger
Type 12C150 inverter with built in charger 1.5kw continuous 3kw surge
500x240x77mm 7.6kg
1.5kw
inverter with charger
Our latest addition to our range of modified sine wave inverters consists of
two new models.

model
|
150 watt
|
330 watt
|
| Input voltage |
10.5 - 14v |
10.5-14v |
| Maximum continuous power |
150 watts |
330 watts |
| Peak power |
300 watts |
600 watts |
| No load current draw |
<0.15A |
<0.25A |
| Weight |
.8kg |
1.1kg |
| Fuse (blade type) |
20 amp |
40 amp |
| Dimensions |
140 x 137 x 52mm |
203 x 137 x 52mm |
| Leads |
fly lead with cigar plug |
Terminals plus fly lead with cigar plug and also a fly lead
with large crocodile clips. |
Features, low battery audible warning, low power shut off, overload
protection, short circuit protection, modified sine wave, temperature
protection, 113A socket outlet.
12v
150 watt inverter
Mains electricity
from your 12v battery. 150watt output (200w peak) 150x90x50mm, standard 13A socket output
and multi national socket, input plugs into cigar socket 90% efficiency 150 x 90 x
50mm,1/2kg weight.
|
